AI Enabled · New Product Launch

EA AI Embedded
Training
Platform

The world's first AI-powered embedded systems training platform — a universal multi-MCU hardware board fused with our custom-built IDE. Compile, flash, debug with step-over/step-into, inspect live register values — all guided by an AI teaching agent that understands your code, your hardware, and your debug session simultaneously.

Request a Demo How It Works ↓
4×
MCU families
8 / 16 / 32-bit / ARM
20+
Onboard
peripherals
1st
AI-native embedded
trainer globally
EA Training Platform PCB
Embedded circuit board AI system
Overview Hardware Board Block Diagram AI Teaching Platform How It Works Who It's For Gallery
The Breakthrough

One platform. Hardware depth.
AI-powered guidance.

The EA AI Training Platform is two innovations in one: a professional-grade universal embedded hardware platform, and a context-aware AI teaching agent that runs alongside your code. Together they make world-class embedded systems education accessible to anyone, anywhere.

🧠

AI Teaching Agent

RAG-powered LLM understands your current source code, recent compilation errors, and the exact MCU you're targeting — giving precise, hardware-aware guidance, not generic answers.

🔌

Universal MCU Platform

One board supports 8-bit (PIC18), 16-bit (dsPIC33), and 32-bit (PIC32MZ) Microchip microcontrollers interchangeably. Learn the full embedded controller spectrum without swapping hardware.

💻

Custom EA IDE

Our in-house developed platform handles everything — write code, compile, flash firmware to the MCU, enter debug mode with step-over / step-into, inspect live register values, and get AI guidance — all without leaving the EA environment.

⚙️

20+ Live Peripherals

Accelerometer, stepper motor, 7-segment display, RTC, RS485, CAN, Ethernet, USB-UART, SPI Flash, DAC — real hardware, not simulations. The AI understands all of them.

🛠️

AI-Aware Debugging

The AI sees your live debug session — step-over, step-into, breakpoints, and real-time register state. When a register holds an unexpected value, the AI explains why and what to fix, right as you debug.

🌍

Global Reach

Replaces the need for local embedded training institutes. Any student anywhere with the board and a laptop has professional-grade embedded mentoring available 24/7.

Hardware Specification

Every peripheral a learner
will ever need.

Component / FeaturePart / Detail
8-bit MCUPIC18 family — up to 128K Flash, USB, segmented LCD, RTCC, 12-bit ADC, 2.0–3.6V
16-bit DSCdsPIC33E — 70 MIPS, integrated DSP, precision motor control, up to 60 MHz
32-bit MCUPIC32MZ EF — 252 MHz, 2MB Flash, 512KB SRAM, USB 2.0, Dual CAN, 6× UART
32-bit ARM MCUPIC32CM5164LS00048 — ARM Cortex-M23, 512KB Flash, 64KB SRAM, 48-pin, TrustZone, low-power IoT
AccelerometerLIS2DE12 — 3-axis MEMS, I²C interface
Stepper Motor DriverMTS2916
7-Segment Displayvia ULN2003ADR driver
Real-Time ClockMCP79402 — I²C
USB–UART BridgeMCP2200
SPI FlashSST25VF512A-33-4CSAE
RS485 TransceiverTHVD1450D
LAN / EthernetENC28J60
CAN BusMCP2551
SPI DACMCP4822 — dual-channel 12-bit
I²C GPIO ExpanderMCP23017 — 16-bit I/O
Digital PotentiometerMCP4561-103
Current SensorMCP6C02
Rotary EncoderPEC16-4220FS0024
Watchdog (WWDT)MCP1320
OpampMCP607
Temperature SensorMCP9700
Additional ModulesBuzzer · Relay · RGB LED · LCD · LDR · ADC POT · 2× Custom Ports
EA Training Platform PCB
// EA Universal Training Platform

MCU & Controller Support Matrix

The same physical board supports all three Microchip MCU tiers. Students progress from 8-bit basics to 32-bit advanced without changing hardware — and the AI teaching agent tracks which MCU is active at all times.

PIC18 · 8-bit · up to 64 MHz PIC32CM5164 · ARM Cortex-M23 · 32-bit dsPIC33 · 16-bit · 70 MIPS PIC32MZ · 32-bit · 252 MHz MPLAB X IDE XC8 / XC16 / XC32 PICkit™ Compatible OpenOCD / JTAG

Upload Your PCB Photos

Click any slot to upload schematics, renders, or board photos.

📷
PCB Top
click to upload
📷
PCB Bottom
click to upload
📐
Schematic
click to upload
System Block Diagram

How the board is wired.

Matrix Keypad
Current Sensor
MCP6C02
Accelerometer
LIS2DE12
Rotary Encoder
PEC16
LDR / ADC POT
Analog In
↓
↓
↓
↓
↓
Digital Pot
MCP4561
→
MCU CORE
PIC18 · dsPIC33 · PIC32MZ
→
RS-485
THVD1450D
↓
↓
↓
↓
↓
Stepper Motor
MTS2916
LAN / ETH
ENC28J60
SPI Flash
SST25VF512A
7-Segment
ULN2003ADR
USB–UART
MCP2200
RTC
MCP79402
CAN Bus
MCP2551
DAC SPI
MCP4822
RGB LED · Buzzer · Relay · LCD · Opamp
AI Teaching Platform

The intelligence behind
the board.

The EA AI Teaching Agent is a RAG-powered LLM system that wraps around the hardware board. It understands embedded concepts, your code, your compiler output, and the specific MCU and peripherals you're working with — simultaneously.

SYSTEM ARCHITECTURE

💻
Layer 1 · Custom EA IDE

EA Embedded Development Platform

Our custom-built IDE — write code, compile with XC8/XC16/XC32, flash firmware to the MCU via USB/PICkit, enter full debug mode (step-over, step-into, breakpoints), and inspect live register values — all in one environment.

↕
⚡
Layer 2 · AI Engine

EA RAG Intelligence Server

Receives live context from the IDE — current source, compiler output, active breakpoint, and register snapshot — performs semantic retrieval, augments the prompt, and streams precise AI guidance back to the IDE in real time.

↕
🗄️
Layer 3 · Knowledge Base

Vector Database

Datasheet knowledge, embedded systems documentation, peripheral configuration guides, code examples — all semantically indexed and updated continuously.

↕
🤖
Layer 4 · Intelligence

LLM Inference Engine

Context-enriched prompt generates precise, hardware-specific guidance, code suggestions, and step-by-step debugging instructions.

↕
🔌
Layer 5 · Physical Ground Truth

EA Training Platform

Real MCU hardware running real firmware — the physical anchor for all AI guidance. The AI always knows which MCU and which peripheral you're targeting.

AI system neural network

What the AI agent knows

Which MCU is active Current source code Compiler errors & warnings Active debug session state Step-over / step-into position Live register values Breakpoint location Peripheral config in use Datasheet sections Flash & program status

Full IDE Capability Stack

The EA platform is not a plugin — it is a fully custom-developed embedded IDE. Compile, flash, debug, and inspect registers without leaving the environment, while the AI agent observes and guides at every step.

XC8 / XC16 / XC32 Compiler USB / PICkit Flash Programming Step-Over Debug Step-Into Debug Breakpoint Management Live Register Viewer AI Inline Guidance

Platform Screenshots

Upload screenshots of the EA IDE, debug sessions, register views, or AI guidance responses.

💻
EA IDE UI
🤖
AI Response
📊
Dashboard
How It Works

From power-on to expert guidance
in seconds.

1

Plug in the EA Trainer Board

Connect via USB. Select your target MCU (8/16/32-bit). The AI agent automatically recognises the hardware configuration, active peripherals, and available toolchain.

2

Open the EA Embedded IDE

The EA AI extension loads your project context — source files, compiler version, MCU family, and previous build output are all captured automatically in the background.

3

Write Code and Ask Anything

Type naturally: "Why is my UART not transmitting?" or "Show me how to configure Timer1 on dsPIC33." The AI retrieves relevant knowledge, maps it to your exact code, and responds inline with precise guidance.

4

Build, Flash, and Observe Real Hardware

Compile with XC, flash via PICkit or USB, and observe real peripheral behaviour on the board. The AI interprets results, explains register states, and guides the next debugging step.

5

Progress Across MCU Families

Swap the MCU on the same board and the AI teaching agent adapts instantly — tracking your new hardware context, relevant datasheets, and changing the guidance accordingly.

Who It's For

For every stage of the
embedded journey.

🎓

Engineering Students

ECE / EEE / CS students building real embedded skills beyond theory — with a professional-grade board and an AI tutor guiding every lab session.

🏫

Training Institutes & Labs

Replace generic trainer kits with a cutting-edge platform. The AI agent scales to every student simultaneously — no instructor bottleneck during lab hours.

👨‍💻

Self-Learning Engineers

Professionals upskilling into embedded or expanding from one MCU family to another — with contextual AI support available 24/7 without waiting for a mentor.

🏭

Corporate Training Programs

Onboard new embedded hires rapidly with consistent, standardised learning outcomes. Accelerates ramp-up from months to weeks across any team size.

// Get Started

Ready to transform how
embedded systems are taught?

Contact us for pricing, institutional bulk orders, and demo board requests. We ship worldwide.
