EA Universal Training Platform
One board. Every controller.
The EA Universal Training Platform is our flagship training and prototyping platform — designed to support 8-bit, 16-bit, and 32-bit Microchip microcontrollers interchangeably with a rich peripheral ecosystem onboard.
| Component / Feature | Detail |
|---|---|
| MCU Support | 8-bit (PIC18), 16-bit (dsPIC33), 32-bit (PIC32MZ) — interchangeable sockets |
| Accelerometer | LIS2DE12 (MEMS 3-axis, I²C) |
| Stepper Motor Driver | MTS2916 |
| 7-Segment Display | ULN2003ADR driver |
| Real-Time Clock | MCP79402 (I²C) |
| USB–UART Bridge | MCP2200 |
| SPI Flash | SST25VF512A-33-4CSAE |
| RS485 Transceiver | THVD1450D |
| LAN / Ethernet | ENC28J60 |
| CAN Bus | MCP2551 |
| DAC (SPI) | MCP4822 |
| I²C GPIO Expander | MCP23017 |
| Digital Potentiometer | MCP4561-103 |
| Current Sensor | MCP6C02 |
| Rotary Encoder | PEC16-4220FS0024 |
| Watchdog Timer (WWDT) | MCP1320 |
| Opamp | MCP607 |
| Temperature Sensor | MCP9700 |
| Additional Modules | Buzzer, Relay, RGB LED, LCD, LDR, ADC POT, Opamp, 2× Custom Ports |
System Block Diagram
Matrix Keypad
Current Sensor
Accelerometer
CAN Interface
Digital Pot
→
MCU CORE
8-bit / 16-bit / 32-bit
→
RS-485
Stepper Motor
LAN / ETH
SPI Flash
7-Segment
USB–UART
RTC (MCP79402)
LED / RGB / Buzzer
DAC / ADC / OPAMP
